The LEEDAX 440 Watt LED Stadium Light Luminary is a high-output outdoor lighting solution engineered for stadiums, sports grounds, large outdoor spaces, construction sites, event grounds and other applications requiring powerful, wide-area illumination. With a system power consumption of 440 Watts and an initial LED lumen output of 51,920–55,000 lumens, this LED Stadium Light is designed to provide strong brightness and extended light coverage for demanding outdoor lighting projects.
The LEEDAX 440W LED Stadium Light is positioned as a powerful mid-range solution within the LEEDAX Stadium Lighting range. It provides significantly higher illumination capability than lower-wattage floodlights while maintaining an efficient balance between lighting performance, structural durability and operating cost. Its optimized LED array and high-efficiency driver are designed to deliver greater usable light output from the electrical power consumed.
A major advantage of this 440 Watt LED Stadium Light is its flexible optical configuration. It incorporates a 120° internal LED beam view angle together with selectable 20°, 60° and 90° LED module view angles, enabling lighting designers to select an appropriate beam configuration for different field sizes, mounting heights and light-throw requirements.
The fixture features a robust aluminium pressure die-cast body, optical-grade PC covering and IP66 protection, making it suitable for demanding outdoor environments exposed to rain, humidity and dust. Anti-glare optical design helps minimize visual discomfort while maintaining strong illumination.
With 50,000 hours LED life, power factor above 0.95, THD below 10%, surge protection above 6 KVA and driver efficiency above 85%, the LEEDAX 440W LED Stadium Light is designed for reliable and efficient long-term operation.
| Product Code | LXFLHP440BX-LN-CW |
| System Power Consumption | 440 Watts |
| Initial LED Lumen Output Range | 51,920 – 55,000 Lm |
| Surge Protection | > 6 KVA |
| Power Factor | > 0.95 |
| THD | < 10% |
| Colour Temperature Range | 3000K / 4000K / 6500K |
| Colour Rendering Index | 70–80 CRI |
| Internal LED Beam View Angle | 120° |
| LED Module View Angle | 20° / 60° / 90° |
| Standard Operating Temperature | -10°C to +65°C |
| Standard Input Voltage | 230V AC |
| Input Working Voltage Range | 145–270V AC |
| Over Voltage Protection | 440V AC |
| IP Protection | IP66 |
| LED Life Span | 50,000 Hours |
| LED LM-80 Report | Available |
| Driver Efficiency | > 85% |
| Body Type | Aluminium Pressure Die Cast |
| Covering | Optical Grade PC |
| Covering Luminous Transmission | 85–90% |
| Covering Refractive Index | 1.584 |
| Covering Flammability | HB / V-0 (UL94) |
| Performance | Soft Narrow Beam with Good Illuminance |
| Application | Stadium Lighting, Outdoor Lighting, Construction |
| Tolerance (+/-) | 10% on all above values |
The LEEDAX 440 Watt LED Stadium Light combines high lumen performance, flexible optical control, rugged construction and reliable electrical protection for demanding stadium and outdoor lighting applications.
High Lumen Output: The 440W LED Stadium Light provides an initial LED lumen output of 51,920–55,000 lumens, delivering powerful illumination for large outdoor areas, sports grounds and stadium applications.
Flexible Beam Configuration: The fixture incorporates a 120° internal LED beam view angle with selectable 20°, 60° and 90° LED module view angles. This provides greater flexibility in directing light according to mounting height, field dimensions and required illumination coverage.
High-Performance LED Technology: The optimized LED array and driver combination is designed to deliver strong usable light output while maintaining efficient electrical performance.
50,000-Hour LED Life: A long rated operating life helps reduce replacement frequency and maintenance requirements, particularly for stadium lights installed at elevated mounting positions.
High Colour Rendering: With a 70–80 CRI rating, the fixture provides improved colour visibility for sporting environments, players, officials and outdoor activities.
Anti-Glare Optical Design: The optical configuration is designed to provide controlled illumination while reducing visual discomfort caused by excessive glare.
IP66 Weather Protection: The IP66-rated construction provides protection suitable for demanding outdoor environments, including exposure to rain, humidity and dust.
Heavy-Duty Aluminium Construction: The reinforced aluminium pressure die-cast housing provides structural strength and supports heat dissipation.
Advanced Electrical Protection: Surge protection above 6 KVA and over-voltage protection up to 440V AC support dependable operation under specified electrical conditions.
Efficient Electrical Performance: Power factor above 0.95, THD below 10% and driver efficiency above 85% contribute to efficient and stable lighting operation.
The LEEDAX 440 Watt LED Stadium Light Luminary is designed to provide substantial benefits for stadium owners, sports facility operators, infrastructure developers, contractors and industrial users seeking powerful and dependable outdoor illumination.
The primary benefit is its high lumen output of 51,920–55,000 lumens, which provides the strong brightness required for larger outdoor areas. The fixture can therefore serve applications where lower-wattage LED floodlights may not provide sufficient illumination or light throw.
Its selectable 20°, 60° and 90° LED module view angles provide greater flexibility in lighting design. This allows the fixture to be configured according to the required light distribution, mounting arrangement and area coverage. Such optical flexibility is particularly valuable in stadiums and sports grounds where controlled light direction is important.
The 50,000-hour LED lifespan can help reduce maintenance frequency and replacement requirements. For stadium lighting installed on high poles, towers or elevated structures, reducing maintenance intervention can be especially beneficial because servicing may require specialized access equipment.
The robust aluminium pressure die-cast housing provides durable construction while supporting thermal management. Combined with IP66 protection, the fixture is designed for demanding outdoor environments.
Another benefit is its electrical protection and efficiency. Surge protection above 6 KVA, over-voltage protection up to 440V AC, power factor above 0.95 and THD below 10% are designed to support reliable electrical operation.
The optical-grade PC covering provides 85–90% luminous transmission, helping efficiently transmit generated light.
Overall, the LEEDAX 440W Stadium Light offers a practical combination of high brightness, controlled light distribution, durability, weather protection, energy efficiency and long service life.
The LEEDAX 440 Watt LED Stadium Light is suitable for a wide range of stadium, sports, outdoor, industrial, construction and large-area lighting applications where powerful and controlled illumination is required.
District & State-Level Stadiums
The 440W LED Stadium Light is suitable for district and state-level stadiums, including football grounds, cricket grounds, athletic tracks and multi-sport venues requiring stronger and farther-reaching illumination.
Sports Academies & University Grounds
Sports academies, colleges and universities can use the fixture for training grounds, competitive sports complexes and outdoor playing areas requiring consistent illumination.
Regional Tournaments & Night Fixtures
The high-output LED Stadium Light is appropriate for night-time sporting events and regional tournaments, where dependable outdoor floodlighting and controlled light distribution are important.
Large Outdoor Public Spaces
City parks, public grounds, recreational areas and other expansive outdoor spaces can use the 440W LED Stadium Light for wide-area illumination.
Industrial & Construction Zones
Construction sites and industrial work areas requiring high-lumen night-time lighting can benefit from the fixture’s rugged construction, high output and outdoor protection.
Expansive Parking & Event Grounds
Large parking areas, fairgrounds, exhibition spaces and outdoor event grounds can use the high-output LED floodlight for broad-area illumination.
Perimeter & Boundary Lighting
The fixture can be used for industrial campuses, large compounds, restricted-access areas and security boundaries requiring extended-throw illumination.
Outdoor Sports & Recreational Facilities
The LEEDAX 440W Stadium Light can also support outdoor sports facilities and recreational grounds requiring powerful, durable and weather-resistant LED lighting.
With its high lumen output, selectable beam options, IP66 protection and long operating life, the LEEDAX 440 Watt LED Stadium Light is a versatile solution for stadium lighting, sports lighting, outdoor floodlighting, construction lighting, industrial outdoor lighting and large-area illumination projects.
