The LEEDAX 330 Watt LED Stadium Light Luminary is a high-output, energy-efficient outdoor lighting solution designed for sports grounds, community stadiums, school and college sports facilities, construction yards, parking areas and other large outdoor spaces requiring powerful and uniform illumination. The 330W LED Stadium Light, Model LXFLHP330BX-LN-CW, provides a practical lighting solution for projects that require strong brightness and controlled energy consumption without moving to very high-wattage stadium lighting systems.
Engineered by LEEDAX Lighting Technologies, this LED Stadium Light combines high-output LED technology, precision optical design and a rugged aluminium pressure die-cast body to provide dependable performance in demanding outdoor environments. With an initial LED lumen output range of 38,940–41,250 lumens, the 330 Watt Stadium Light is designed to provide strong illumination appropriate for mid-scale sports and outdoor lighting projects.
The luminaire features a 120° internal LED beam view angle together with selectable 20° / 60° / 90° LED module view angles, allowing the optical configuration to be matched to different lighting requirements and throw distances. Its anti-glare optical design is intended to minimize harsh glare and provide comfortable visibility for players, spectators and users of outdoor facilities.
With IP66 protection, the LED Stadium Light is designed to withstand outdoor exposure to rain, dust and humidity. Surge protection above 6 KVA, over-voltage protection up to 440V AC, power factor above 0.95 and THD below 10% further support reliable electrical performance.
| Model Number | LXFLHP330BX-LN-CW |
| System Power Consumption | 330 Watts |
| Initial LED Lumen Output Range | 38,940 – 41,250 Lm |
| Surge Protection | > 6 KVA |
| Power Factor | > 0.95 |
| THD | < 10% |
| Colour Temperature Range | 3000K / 4000K / 6500K |
| Colour Rendering Index | 70–80 CRI |
| Internal LED Beam View Angle | 120° |
| LED Module View Angle | 20° / 60° / 90° |
| Standard Operating Temperature | -10°C to +65°C |
| Standard Input Voltage | 230V AC |
| Input Working Voltage Range | 145–270V AC |
| Over Voltage Protection | 440V AC |
| IP Protection | IP66 |
| LED Life Span | 50,000 Hours |
| LED LM-80 Report | Available |
| Driver Efficiency | > 85% |
| Body Type | Aluminium Pressure Die Cast |
| Covering | Optical Grade PC |
| Covering Luminous Transmission | 85–90% |
| Covering Refractive Index | 1.584 |
| Covering Flammability | HB / V-0 (UL94) |
| Performance | Soft Narrow Beam with Good Illuminance |
| Application | Stadium Lighting, Outdoor Lighting, Construction |
| Tolerance (+/-) | 10% on all above values |
The LEEDAX 330 Watt LED Stadium Light is engineered with a combination of high lumen output, adjustable optical performance, weather protection, electrical safety and robust construction for demanding sports and outdoor lighting applications.
High Lumen Output
With an initial LED lumen output range of 38,940–41,250 lumens, the 330W LED Stadium Light is designed to deliver strong and dependable brightness for mid-scale stadiums, sports grounds and outdoor facilities.
Adjustable Optical Performance
The luminaire incorporates a 120° internal LED beam view angle with selectable 20° / 60° / 90° LED module view angles. This allows the lighting distribution and throw characteristics to be adapted to different project requirements.
Uniform Illumination
The precision optical system is designed to distribute light effectively across sports grounds and outdoor areas, helping reduce dark patches and inconsistent brightness.
Anti-Glare Optical Design
The optical configuration is designed to reduce harsh glare and visual discomfort, supporting better visibility for players, spectators and other users.
Long Operational Life
With a rated LED lifespan of up to 50,000 hours, the LED Stadium Light can reduce replacement frequency and maintenance requirements.
IP66 Weather Protection
The IP66-rated construction provides protection suitable for outdoor environments exposed to rain, dust and humidity.
Robust Aluminium Construction
The heavy-duty aluminium pressure die-cast body provides structural strength and supports heat dissipation during continuous operation.
High Electrical Efficiency
Driver efficiency above 85%, power factor above 0.95 and THD below 10% support efficient and stable electrical operation.
Surge & Voltage Protection
Surge protection exceeding 6 KVA and over-voltage protection up to 440V AC provide additional protection against electrical fluctuations.
High-Quality Optical Cover
The optical-grade PC covering provides 85–90% luminous transmission, with a refractive index of 1.584 and HB / V-0 (UL94) flammability specifications.
Flexible Colour Temperature
The availability of 3000K, 4000K and 6500K colour temperature options provides flexibility for different sports and outdoor lighting requirements.
The LEEDAX 330 Watt LED Stadium Light Luminary provides a combination of illumination performance, energy efficiency, durability and reduced maintenance for sports and outdoor lighting projects. Its engineered optical system and robust construction make it suitable for organizations looking for a dependable 330W LED Stadium Lighting Solution.
Strong Illumination
The high initial lumen output of 38,940–41,250 lumens provides strong brightness for sports grounds, outdoor venues, construction areas and other large spaces requiring dependable illumination.
Better Light Distribution
The combination of a 120° internal beam view and selectable 20°, 60° and 90° module view angles provides flexibility in directing light toward the required area.
Reduced Glare
The anti-glare optical design helps minimize harsh direct glare, supporting improved visual comfort for players, spectators, workers and visitors.
Energy-Efficient Operation
The 330W LED system, together with driver efficiency above 85% and power factor above 0.95, supports efficient utilization of electrical power.
Lower Maintenance
A 50,000-hour LED lifespan helps reduce the frequency of lamp replacement and associated maintenance activity, particularly for fixtures installed at height.
Outdoor Durability
IP66 protection helps the luminaire withstand outdoor exposure to rain, dust and humidity, making it appropriate for demanding outdoor installations.
Reliable Electrical Performance
Surge protection above 6 KVA, over-voltage protection up to 440V AC and THD below 10% contribute to dependable operation under varying electrical conditions.
Improved Visibility
High lumen output combined with controlled optical distribution can provide improved visibility across sports grounds, parking areas, construction sites and outdoor event spaces.
Long-Term Value
The combination of long LED life, efficient operation, durable construction and reduced maintenance can help control the overall operating cost of outdoor lighting installations.
Versatile Application
The 330 Watt LED Stadium Light can be used across sports, educational, recreational, industrial, construction and security applications, making it a versatile high-output outdoor LED lighting solution.
The LEEDAX 330 Watt LED Stadium Light Luminary is designed for mid-scale sports, outdoor, industrial and recreational lighting applications where high lumen output, uniform illumination and reliable outdoor performance are required. Its adjustable optical configuration makes it suitable for projects where light needs to be directed accurately toward specific areas.
Sports Grounds & Community Stadiums
The 330W LED Stadium Light is suitable for football fields, cricket grounds, community stadiums and multi-purpose sports arenas requiring strong and uniform outdoor illumination.
School & College Sports Facilities
Educational institutions can use the luminaire for athletic tracks, playgrounds, sports grounds and indoor-outdoor sports complexes, providing dependable lighting for training, activities and events.
Local & Regional Tournaments
The high lumen output and high-CRI performance make the product suitable for night matches, tournaments and community-level sporting events where reliable illumination is required.
Outdoor Recreational Venues
The LED Stadium Light can be installed in public parks, sports clubs, open play areas and recreational grounds requiring broad-area outdoor illumination.
Construction & Industrial Yards
Construction sites and industrial yards often require reliable lighting for night-time operations. The IP66-rated 330W Stadium Light provides a robust option for these demanding environments.
Parking Lots & Open Grounds
Large paved areas, exhibition grounds, event spaces and open parking areas can benefit from wide and controlled light coverage.
Perimeter & Security Lighting
The adjustable module view angles make the luminaire suitable for boundary walls, campus perimeters, restricted zones and security-sensitive outdoor areas requiring reliable long-throw illumination.
Outdoor Event Spaces
The product can also support temporary or permanent outdoor event areas where high-output and dependable lighting is required.
Overall, the LEEDAX 330 Watt LED Stadium Light is a versatile solution for stadiums, sports grounds, schools, colleges, construction sites, industrial yards, parking areas, recreational venues and outdoor facilities.
