The LEEDAX 100 Watt LED Highbay Light Luminary is a high-performance, energy-efficient industrial lighting solution designed for factories, warehouses, manufacturing units, industrial sheds, workshops and commercial spaces requiring strong and uniform illumination. With its optimized 100W power consumption, high lumen efficiency and wide-area light distribution, this 100 Watt LED Highbay Light is ideally positioned between compact lighting fixtures and higher-wattage industrial highbay systems.
Manufactured by LEEDAX Lighting Technologies, the LXHBYLP100BX is engineered with a carefully calibrated LED array, high-efficiency LED driver, optimized reflector geometry and robust aluminium pressure die-cast housing. This combination is designed to deliver high lumen output, effective thermal management and dependable long-term performance.
The 100W LED Highbay Light incorporates a 120° internal LED beam view angle to provide broad and uniform illumination across industrial floors, storage areas and wider working spaces. Its driver efficiency of more than 85%, power factor above 0.95 and THD below 10% contribute to efficient electrical operation and reduced power wastage.
The luminaire offers a 50,000-hour LED lifespan, reducing the frequency of replacement and maintenance, particularly in installations where lighting fixtures are mounted at considerable height. IP55/IP65 protection options, toughened glass covering and surge protection exceeding 6 KVA further enhance its suitability for demanding industrial environments.
| Product Code | LXHBYLP100BX |
| System Power Consumption | 100 Watt |
| Surge Protection | > 6 KVA |
| Power Factor | > 0.95 |
| THD | < 10% |
| Colour Temperature Range | 3000K / 4000K / 6500K |
| Colour Rendering Index | > 80 CRI |
| Internal LED Beam View Angle | 120° |
| Standard Operating Temperature | -10°C to +65°C |
| Standard Input Voltage | 230V AC |
| Input Working Voltage Range | 145–270V AC |
| Over Voltage Protection | 440V AC |
| IP Protection | IP55 / IP65 (Optional) |
| LED Life Span | 50,000 Hours |
| LED LM-80 Report | Available |
| Manufacturer | LEEDAX |
| Manufacturing Place | Made in India |
| Driver Efficiency | > 85% |
| Body Type | Aluminium Pressure Die Cast |
| Covering | Toughened Glass |
| Application | Industries, Warehouses, Malls, Super Markets, etc. |
| Tolerance (+/-) | 10% on all above values |
The LEEDAX 100 Watt LED Highbay Light combines high-lumen performance, energy efficiency, durable construction and electrical protection to provide dependable lighting for industrial and commercial applications.
High Lumen Efficiency
The precisely calibrated LED array is designed to deliver strong lumen output at 100 watts, making the luminaire suitable for applications requiring enhanced illumination across wider floor areas.
Optimized Lux Distribution
The 120° internal LED beam view angle and optimized optical design provide broad and uniform illumination, helping reduce dark and uneven areas across factories, warehouses and commercial spaces.
Energy-Efficient LED Technology
The 100W LED Highbay Light is designed to provide high illumination while maintaining controlled energy consumption. Driver efficiency above 85% supports efficient conversion of electrical power into useful light.
High Power Factor
With a power factor greater than 0.95 and THD below 10%, the luminaire is engineered for efficient electrical performance and reduced electrical losses.
50,000-Hour LED Life
The long LED lifespan of up to 50,000 hours reduces the frequency of replacement and helps minimize maintenance requirements, particularly in high-ceiling installations.
Heavy-Duty Construction
The aluminium pressure die-cast body provides structural strength and supports effective heat dissipation, while the toughened glass cover provides protection for the optical assembly.
IP55/IP65 Protection
The optional IP55/IP65 protection makes the LED Highbay Light suitable for industrial environments and selected semi-outdoor applications where protection from dust and moisture is required.
Electrical Protection
Surge protection above 6 KVA and over-voltage protection up to 440V AC help improve reliability under varying electrical supply conditions.
High Colour Rendering
With CRI greater than 80, the luminaire provides good colour rendering for applications where clear visual identification and workplace visibility are important.
Made in India
The product is manufactured in India by LEEDAX, providing customers with a Made in India LED Highbay Light backed by controlled in-house manufacturing and quality processes.
The LEEDAX 100 Watt LED Highbay Light Luminary is designed to deliver practical operational benefits for factories, warehouses, manufacturing units, commercial establishments and other large indoor spaces. Its combination of efficient LED technology, durable construction and long operating life can help organizations improve lighting performance while controlling operating and maintenance costs.
Reduced Energy Consumption
The 100W LED configuration is designed to deliver high lumen output with controlled electrical consumption. This makes the product suitable for businesses seeking an energy-efficient LED Highbay Light for continuous industrial or commercial operation.
Lower Maintenance Requirements
With a rated LED life of 50,000 hours, the need for frequent replacement is reduced. This is particularly valuable in high-ceiling areas where changing lighting fixtures can require additional manpower, access equipment and operational downtime.
Better Workplace Visibility
The optimized optical system and 120° beam angle provide wide and uniform illumination. Improved lighting can support visibility across production floors, warehouse aisles, assembly areas, workshops and commercial spaces.
Long-Term Reliability
The combination of aluminium pressure die-cast construction, toughened glass, quality LED components and electrical protection provides a durable lighting solution designed for demanding operating environments.
Improved Electrical Performance
A power factor above 0.95, THD below 10% and driver efficiency above 85% support efficient electrical operation and help minimize unnecessary energy losses.
Reduced Total Operating Cost
Energy-efficient operation combined with long LED life and reduced maintenance requirements can contribute to lower total ownership and operating costs over the product’s service life.
Flexible Lighting Options
The availability of 3000K, 4000K and 6500K colour temperature options allows the 100W LED Highbay Light to be selected according to the lighting requirements of different industrial, commercial and storage environments.
Suitable for Industrial Conditions
IP55/IP65 protection options, surge protection above 6 KVA and over-voltage protection up to 440V AC provide additional protection for demanding applications.
Factory-Direct Supply
As a 100 Watt LED Highbay Light Manufacturer in India, LEEDAX provides factory-direct manufacturing and supply, supported by in-house production and quality control.
The LEEDAX 100 Watt LED Highbay Light Luminary is designed for industrial and commercial environments where higher lumen output, broad illumination and reliable long-term performance are required. Its 100W configuration makes it particularly suitable for mid-sized factories, warehouses, manufacturing areas and commercial spaces with wider floor areas and higher illumination requirements.
Mid-Sized Factories & Manufacturing Units
The 100W LED Highbay Light can be used on production floors where stronger and more uniform illumination is required for manufacturing activities, machinery operation and general workplace visibility.
Warehouses & Godowns
Warehouses and godowns with higher ceilings can benefit from the high-lumen output and broad 120° beam distribution. The luminaire is suitable for storage areas, inventory handling zones and warehouse aisles.
Assembly Halls & Large Store Rooms
Assembly halls and larger storage areas require consistent illumination across wider floor spans. The LEEDAX Highbay Light provides broad-area lighting suitable for these environments.
Industrial Sheds & Processing Units
The durable aluminium die-cast construction and optional IP55/IP65 protection make the luminaire suitable for industrial sheds and processing areas where durability and protection against dust and moisture are important.
Workshops
Workshops requiring enhanced visibility for machinery, assembly and precision activities can use the 100W LED Highbay Light to achieve improved illumination and colour rendering.
Supermarkets, Malls & Commercial Complexes
The luminaire can also be applied in larger retail and commercial environments where efficient, long-lasting overhead lighting is required.
Covered Parking Structures
Covered parking areas and multiplex parking structures can use the wide beam distribution of the LED Highbay Light for broad illumination across mid-height spaces.
Cold Storages & Distribution Centres
Cold storage and distribution facilities can benefit from the energy-efficient, long-life and low-maintenance characteristics of the 100W LED Highbay Light for extended operating schedules.
Overall, the LEEDAX 100 Watt LED Highbay Light is suitable for factories, warehouses, godowns, industrial sheds, workshops, malls, supermarkets, commercial buildings, distribution centres and covered parking areas requiring dependable high-lumen LED lighting.
